1
YXL SERIES
YXL15SP Powered Subwoofer
The YXL15SP offers our best ratio of power, performance and value for an active subwoofer
enclosure. Providing 500 watts (1000 watts peak) with efficient speaker components, the YXL
Series is extremely loud for its size. The YXL15SP can be easily used in any situation, close to
walls, floors or in arrays with multiple enclosures.
Features
• 1000 watts (peak) 500 watts (program)
• Superior DSP processing with component protection
• 15-inch woofer with 3-inch voice coil
• Recessed control panel
• Master Level control with Activity indicator (cabinet level adjustment)
• 3 Performance modes, Punch, Smooth and Deep
• 2 x XLR/ 1/4-inch Combi Inputs
• 2 x XLR Link outputs
• 12 mm plywood, latex paint
• Tough, full length metal grille
1. Power LED Indicator
The power switch is located at the bottom of the
rear panel. The Power LED, located near the top
of the plate, indicates when the unit is on.
2. Mode Switch
EQ and tone settings.
• Punch Mode will process the sound
so it is perceived as a punchier sound,
giving less power into deep bass and
more into the upper bass.
• Smooth Mode will keep the original
signal character with no preference for
deep or upper bass.
• Deep mode will process the signal to
provide a deeper sound, giving more
power into deep bass while keeping the
upper bass similar to the Smooth Mode.
3. Sub Level Control
Independently sets the audio level.
4. Activity LED
Illuminates when signal is sent to the Master.
5. Input
Left/Right Inputs
6. Link
Left/Right Links
