9
English
Getting Started
Installing the Batteries
1. Turn the radio off.
2. Press the tab at the bottom of the compartment door to
remove the battery compartment door.
3. Remove the door.
4. Insert three AAA batteries into the battery compartment.
5. Replace the battery compartment door.
Battery Level and Low Battery Alert
Removing the Alkaline Batteries
1. Turn the radio off.
2. With the back of the radio facing you, lift the battery cover
latch and remove the cover.
3. Remove each alkaline battery.
4. Close the battery cover.
Note:
• Exercise care when removing AAA batteries. Do not use
sharp or conductive tools to remove either of these
batteries.
• Remove the batteries before storing your radio for
extended periods of time. Batteries corrode over time and
may cause permanent damage to your radio.
Attaching the Belt Clip
1. Attach the belt clip to the back of the radio until the clip
clicks in place.
2. Attach the belt clip to pocket or belt strap until the clip
clicks in place.
Removing the Belt Clip
1. Pull the release tab on top of the belt clip to release the
latch.
2. Push the belt clip with the other hand towards the top of
radio.
Basic Radio Operations
Read this reference guide completely before attempting to
operate the unit.
Turning Your Radio On/Off
Press and hold the / button to turn your radio
on/off.
Adjusting the Volume
1. Adjust the volume by pressing the and buttons.
2. When the volume reached level 0, the icon appears
permanently on screen.
This icon will show when battery is low and
will blink when battery is extremely low.
Replace the batteries immediately.
