Curtis SP258 - Manuel

Bluetooth Speaker
Model:SP258
Please read these instructions thoroughly
before use and retain for future reference.
Safety Instructions
The lighting flash with arrowhead symbol, within an equilateral
triangle, is intended to alert user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure, that may be
of sufficient magnitude to constitute a risk of electric.
The exclamation point within an equilateral triangle is intended to
alert user to the presence of important operating and maintenance
(servicing) instruction in the literature accompanying the
appliance.
FCC NOTICE:
This equipment has been tested and found to comply with the limits for
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception. Which can be determined by encouraged to
try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, follow the attached installation
instructions and use only shield cables when connecting to other
devices. Modifications not authorized by the manufacturer may void
user’s authority to operate this device.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DON’T REMOVE
COVER ( OR BACK ). NO
USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Before using the unit, be sure to read all operating instruction
carefully, please note that these are general precautions and may not
pertain to your unit. For example, this unit may not have the capability
to be connected to an outdoor antenna.
1. Read these instructions
All safety and operating instructions should be read before the product
is operated.
2. Keep these instructions
The safety and operating instructions should be retained for future
reference.
3. Heed all warnings
All warnings on the product and in the operating instruction manual
should be adhered to.
4. Follow these instructions
All operating and use instructions should be followed.
5. Do not use this apparatus near water
Do not use the product near water and moisture, for example:near a
bathtub, washbowl, kitchen sink or laundry tub; in a wet basement; or
near a swimming pool.
6. Clean only with dry cloth
Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a dry cloth for cleaning.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
Slots and openings in the cabinet and in the back or bottom are
provided for ventilation, to ensure reliable operation of the product and
to protect it from overheating. These openings must not be blocked or
covered.The openings should never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This product should never
be placed near or over a radiator or heat source. This product should
not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions
have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand , tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture does not operate normally, or has been
dropped.
Instructions for use
Please read all instructions carefully
Getting started
Remove the speaker from the box
Remove any packaging from the product
Place the packaging inside the box and store for safekeeping
In the box
Bluetooth speaker
USB charging cable
Instruction manual
Features
- Can be used with any Bluetooth device.
- Can also be used with all MP3 players or devices with a headphone
socket.
- Built in microphone for hands free use with Bluetooth devices.
- 2x2W stereo speakers.
- Built in Lithium rechargeable battery.
- Up to 8 hours continuous music.
Product Overview
1. Bluetooth( Blue LED)/AUX IN ( Red LED 1)Indicator
2. Built-in Microphone
3. Charging Indicator(Red LED 2)
4. PLAY/PAUSE (Pair/Hand-free) Button
5. Volume Increase ( Next)Button
6. Volume Decrease (Previous)Button
7. POWER ON/OFF Switch
8. AUX IN jack
9. Charging Port
If required, enter the password ‘ 0000’ to confirm to pairing.
Once paired successfully, the blue LED will flash slowly.
The speaker will remember this device and will pair automatically when the
device’s Bluetooth is activated and in range. You do not need to re-pair any
previously connected devices.
If you need to pair with another device after pairing successfully, press and
hold the button to search for the new device.
Please Note
• Not all devices have the same operation. Please refer to your device’s
user’s manual for further information.
• If the speaker cannot pair up with new device for around 2.5 minutes,
turn off the speaker and reboot to pair.
Listening to Music
Once the speaker is paired with your device you can stream music
wirelessly through the speaker. Should you encounter any problems while
streaming please refer your device’s user manual for further information.
Instructions for use (AUX IN cable)
You may also connect any device with a headphone socket using the
3.5mm audio cable . Connect this cable to your headphone socket of your
device and to the AUX IN jack. The Red LED 1 will light.
Control Functions
Function Operation Button
Increase Volume
(Skip to Next Track) Playing music
Decrease
Volume(Skip to
Previous Track)
Playing music
Pause Playing music A short press on the button
will pause the music
Play Pausing music A short press on the button will restart the music
(Note: Above mentioned functions can be used in Bluetooth mode only. In
Aux In mode, you need to control through your source device except for
volume up and down function. )
An indication tone will alert you when the volume is adjusted to the
maximum or minimum level.
Making a phone call with the device in Bluetooth mode
Basic operation
Function Operation Button
Answer A Call Incoming Call A short press the once to answer
an incoming call.
Reject a call Incoming Call Double press the button to refuse
an incoming call.
End a call Incoming Call
After your phone conversation,
Short press the button to end a
call.
Increase Volume During a call Press and hold the + button will
increase the volume.
Decrease
Volume During a call
Press and hold the - button will
decrease the volume.
Redial last
number
music status
and connected
to a device
Double press the button to redial
last number.
Do's and Don’ts
• Do not expose the speaker to liquid, moisture or humidity to avoid the
product’s internal circuit being affected.
• Don’t use abrasive cleaning solvents to clean the speaker.
• Do not expose the speaker to extremely high or low temperature as this
will shorten the life of electronic devices, destroy the battery or distort
certain plastic parts.
• Don’t dispose of the speaker in a fire as it will result in an explosion.
• Don’t expose the speaker to contact with sharp objects as this will
cause scratches and damage.
• Don’t let the speaker drop on to the floor. The internal circuitry might
get damaged.
• Don’t attempt to disassemble the speaker as it may get damaged if you
are not professional.
Specifications
Bluetooth 2.1+EDR
Operating distance Above 10 meters
Working time
Up to 8 hours
Battery Play time will vary
based on volume level
Charging time About 4 hours
Speaker power 2 x 2W
Built-in Battery 1000mAh
Dimensions 175 X 56 X 74.2 mm
is a trademark on a registered trademark of Bluetooth
SIG Inc.
Made in China
1 2 3
4 5 6 7
Instructions for use (Bluetooth pairing)
Turn ON the unit.
You would now hear a Beep tone indicating that the speaker is pairing with
the last device.
The Blue LED flashes quickly.
Turn on the Bluetooth function on your Bluetooth Device (Mobile Phone or
Tablet). Please refer to manufacturer’s instructions for instructions on
enabling Bluetooth on your device.
Once you have turned on Bluetooth on your device, select the device
“SP258” from the list of available Bluetooth devices.
Press and hold the + button to
increase the volume
A short press the + button to
skip to Next track
Press and hold the - button to
decrease the volume
A short press the - button to
skip to Previous track
Charging Instructions
The speaker comes with a built in rechargeable battery.
Connect the Micro USB cable to a computer USB port and the other plug
to the charging Micro USB port of the speaker. The Red LED 2 illuminates
while the speaker is charging. It takes around 4 hours for the unit to fully
charge. When the battery is fully charged the Red LED 2 will switch off.
Cleaning & Maintenance
Please use soft cloth to clean the speaker and do not attempt to
disassemble the speaker.
