31
COMPONENT IDENTIFICATION
LEFT SIDE VIEW -- VEGAS / VEGAS EIGHT BALL
1. Front Fork
2. Front Turn Signal
3. Headlamp
4. Air Filter
5. Spark Plug (2)
6. Ignition Switch
7. Left Side Cover
8. Battery (under side cover)
9. Taillight
10. Rear Turn Signal
11. Rear Axle Adjuster (1 each side)
12. Rear Brake Caliper
13. Passenger’s Foot Rest
(except VEGAS EIGHT BALL)
14. Evaporative Canister -
California Models
15. Engine Oil Filter
16. Engine Oil Drain Plug
(under engine)
17. Sidestand
18. Operator’s Foot Rest
19. Gear Shift Lever
20. Horn
21. Front Brake Caliper
1
2
3
4
6 7 8
9
10
11 12
17
20 21
5
14 15 16 16 17 13 18 19
