1. Tip the hanger up and attach it over the the top edge of
the front or rear of the cart as shown at right.
2. Swing it down into position so it "snaps" into place
against the posts.
3. Attach bin or waste basket.
front or rear of top shelf
1 2
3 3
CAUTION:
WEIGHT CAPACITY
25 lbs. (12.5kg)
Assembly Manual
*
*
*Important: middle shelf
must be at least 5 post
grooves below top shelf.
*Important: middle shelf
must be at least 11 post
grooves below top shelf.
Bin Hanger Waste Basket Hanger
Bin Hanger Waste Basket Hanger
Deep Ledge Utility Cart Accessories
