Maytag MGT8820DS - Manuel (Page 7)

7
To Clean:
IMPORTANT: Before cleaning, make sure all controls are off and
the oven and cooktop are cool. Do not use oven cleaners, bleach
or rust removers.
1. Remove the burner cap from the burner base and clean
according to “General Cleaning” section.
2. Clean the gas tube opening with a damp cloth.
3. Clean clogged burner ports with a straight pin as shown. Do
not enlarge or distort the port. Do not use a wooden toothpick.
If the burner needs to be adjusted, contact a trained repair
specialist.
4. Replace the burner cap, making sure the alignment pins are
properly aligned with the burner cap.
5. Turn on the burner. If the burner does not light, check cap
alignment. If the burner still does not light, do not service the
sealed burner yourself. Contact a trained repair specialist.
Grates
The grates on this range cover the full width of the cooktop. The
two grates may interlock (on some models), using the hook formed
into one end of both grates. The flat end of one grate drops onto
the hook on the other grate as shown in the following illustration.
On some models, the two grates are identical and can be used on
either the left or right side of the cooktop. Grates that are designed
for use on only one side of the cooktop will have either “LEFT” or
“RIGHT” embossed on the bottom side of the grate.
Burner Size
Select a burner that best fits your cookware. See the following
illustration and chart.
Cookware
IMPORTANT: Do not leave empty cookware on a hot surface
cooking area, element or surface burner.
Ideal cookware should have a flat bottom, straight sides and a well-
fitting lid, and the material should be of medium-to-heavy
thickness.
Rough finishes may scratch the cooktop or grates. Aluminum and
copper may be used as a core or base in cookware.
Cookware material is a factor in how quickly and evenly heat is
transferred, which affects cooking results.
Cookware with nonstick surfaces should not be used under the
broiler.
Check for flatness by placing the straight edge of a ruler across the
bottom of the cookware. While you rotate the ruler, no space or
light should be visible between it and the cookware.
A. Incorrect
B. Correct
A
B
Burner Size Recommended Use
Small ■ Low-heat cooking
■ Melting chocolate or butter
Oval ■ For longer dishes
Large ■ For large cookware
Extra-Large ■ Most powerful burner
■ For large cookware
Oval
Large
Extra
Large
Small
Front of Range
Back of Range
Small
(on some models)
