LED DISPLAY AND SETTINGS
When you select a cycle, its default settings will light up and
the Estimated Time Remaining (for Sensor Cycles) or actual
time remaining (for Timed Cycles) will be displayed.
Touch the setting names next to the display to adjust settings.
See “Cycle Guide” for available settings on each cycle.
Not all settings are available with all cycles.
Temperature
When using Timed Cycles or Custom Refresh, you may
select a dry temperature based on the type of load you are
drying. Use the warmest setting safe for the garments in
the load. Follow garment label instructions.
NOTE: Sensor Cycles use a preset temperature that is
not adjustable.
Dryness Level
You may adjust the Dryness Level on Sensor Cycles
(except for the Sanitize cycle), if desired.
NOTE: Dryness Level is for use with Sensor Cycles only.
Wrinkle Prevent
If you will be unable to remove a load immediately, touch
Wrinkle Prevent to add up to 120 minutes of periodic
tumbling to help reduce wrinkling. On some cycles, you
may select the “With Steam” setting to add a short steam
cycle after 60 minutes to help smooth out wrinkles.
Garments
This setting allows you to enter the number of items you
are placing in the dryer for the Custom Refresh cycle.
The number of items determines the cycle time.
OPTIONS
Use to select available options for your dryer. Not all cycles
and options are available on all models.
Drum Light
Touch to turn the LED drum light on or off. The light
will also turn on when the door is open, and turn off
automatically after about 5 minutes.
Reduce Static
Touch to add the Reduce Static option to selected
Sensor cycles (see “Cycle Guide”). The dryer will
automatically tumble, pause, and introduce a small amount
of moisture into the load to help reduce static. This option
adds approximately 8 minutes to the total cycle time.
5
Steam Boost
Steam Boost adds steam to the end of the Heavy Duty,
Bedding, Normal, or Garments cycle to help smooth
wrinkles. Steam Boost can be used with High or
Medium heat settings.
Damp Dry Signal
Touch to select the Damp Dry Signal. When selected, a
series of beeps will sound when the load is damp, but not
completely dry. This will allow you to take clothes out of
the load that do not need to dry completely. This option is
available on Heavy Duty, Normal, Bedding, and Delicates
cycles.
Cycle Signal
Use this to turn the signal indicating the end of a drying
cycle on or off.
NOTE: You may also turn off the tones that sound when
a feature, setting, or option is touched. Touch and hold
Cycle Signal for about one second to turn sounds on
or off.
Control Lock
Use to lock the controls of the dryer and avoid
an accidental change in cycle options or preferences
during a drying cycle.
NOTE: The Control Lock function may be enabled when
recovering from a power failure. To unlock the control,
touch and hold CONTROL LOCK for at least 3 seconds.
CYCLE STATUS LIGHTS
The indicator bar on the right side of the control will let you
know what stage of the drying cycle is in process. For more
information on each stage, see “Cycle Status Indicators.”
