25
Préparation
Connexions
Lecture
Réglages
Conseils
Annexe
FRANÇAIS
• Sortie d’alimentation RMS:
(2 canaux 20 Hz − 20 kHz fonctionnant
simultanément)
90 W × 2 (8 Ω/ohms)
140 W × 2 (4 Ω/ohms)
• Distorsion harmonique totale:
(2 canaux 20 Hz − 20 kHz fonctionnant
simultanément, 8 Ω/ohms)
0,05 %
• Largeur de la bande de sortie:
(8 Ω/ohms, 0,05 %)
5 Hz − 40 kHz
• Réponse de fréquence:
(CD, 1 W, charge 8 Ω/ohms)
5 Hz − 100 kHz ± 3 dB
• Taux d’humidité: (8 Ω/ohms, 20 Hz − 20 kHz) 100
• Sensibilité d’entrée / Impédance d’entrée
PHONO (MC): 270 µV / 100 Ω/ohms
PHONO (MM): 2,7 mV / 47 kΩ/kohms
CD/LINE: 240 mV / 20 kΩ/kohms
P. DIRECT IN: 1,7 V / 20 kΩ/kohms
• Tension de sortie / Impédance de sortie
PRE OUT: 1,7 V / 220 Ω/ohms
• Niveau d’entrée PHONO autorisé maximum
(1 kHz)
MC: 15 mV
MM: 150 mV
• Variation RIAA: (20 Hz−20 kHz) ± 0,5 dB
• S/N (IHF-A, 8 Ω/ohms)
PHONO (MC): 75 dB (entrée 0,5 mV, sortie 1 W)
PHONO (MM): 86 dB (entrée 5 mV, sortie 1 W)
CD/LINE: 106 dB
(entrée 2 V, puissance nominale)
• Contrôle de la tonalité
BASS (50 Hz): ± 10 dB
TREBLE (20 kHz): ± 10 dB
• Spécifications d’alimentation: AC 120 V, 60 Hz
• Consommation électrique (UL60065): 220 W
• Consommation en mode veille: 0,2 W
Pour des raisons d’amélioration, les caractéristiques et l’apparence sont susceptibles d’être
modifiées sans avertissement préalable.
Spécifications
v A
Accessoires ·························································· 1
v C
Câbles utilisés pour les connexions ····················· 7
Circuit de protection ··········································· 24
Connexion
Amplificateur de puissance······························ 14
Bornes de télécommande ······························· 15
Connexion complète double amplificateur
stéréo································································11
Cordon d’alimentation······································ 15
Enceintes ··························································· 8
Enregistreur ······················································· 9
F.C.B.S. ····························································· 10
Lecteur ······························································· 8
Lecture multi-canaux 5.1 ································· 12
Préamplificateur ··············································· 14
Conseils ······························································ 20
Coupure temporaire du son ······························· 17
v D
Dépistage des pannes ········································ 20
v I
Impédance des enceintes ·································· 24
v M
Mise sous tension ·············································· 16
Mode veille automatique ···································· 19
v P
Panneau arrière ···················································· 5
Panneau avant ······················································ 4
v R
Réglage de la tonalité ········································· 17
Réglage du volume ············································· 16
v S
Sélection de cellule MM/MC ······························ 24
Sélection de la source d’entrée ·························· 16
v T
Télécommande ···················································· 6
Insertion des piles·············································· 2
Index
