Panneau arrière – Marantz SR6005 Manuel d'utilisation
Page 83
79
Version basique
Version avancée
Version simplifiée
ENGLISH
FRANÇAIS
ESPAÑOL
DEUTSCH
ITALIANO
NEDERLANDS
SVENSKA
Informations
Panneau arrière
Voir la page indiquée entre parenthèses ( ).
q
y
t
e
r
w
Q5
Q6
u
Q0
o
Q1
Q4
Q3
Q2
i
q
Bornes d’antennes HD Radio ················································· (21)
w
Bornes audio analogiques ·········································· (17, 18, 20)
e
Bornes PRE OUT ·····················································(6, 23, 36 – 38)
r
Bornes 7.1CH INPUT ······························································· (22)
t
Bornes d’enceintes ·······················································(6, 36 – 38)
y
Prise CA (AC IN) ········································································· (6)
u
Bornes COMPONENT VIDEO ············································ (17, 18)
i
Bornes HDMI ············································································ (16)
o
Bornes audio numériques ··········································· (17, 18, 20
Q0
Bornes VIDEO ···································································· (17, 18)
Q1
Prise FLASHER IN
Utilisé avec un BOITIER de commande ou autre dispositif de
commande pour la gestion de cet appareil.
Q2
Prises REMOTE CONTROL ······················································ (40)
Q3
Prise M-Xport ··········································································· (21)
Q4
Borne SIRIUS ··········································································· (20)
Q5
Prises DC OUT ········································································· (41)
Q6
Borne RS-232C ········································································· (41)
REMARQUE
Ne touchez pas les broches internes des connecteurs sur le panneau
arrière. Une éventuelle décharge électrique pourrait endommager de
façon permanente votre appareil.
