Cabasse STREAM source - Manuel (Page 23)

22 23
STREAM SOURCE
Digital inputs
- 1 DLNA input: either wired with RJ45 cable or WiFi
- 1 Bluetooth APTX input
- 1 USB input
Ouputs
- 1 analog RCA
- 1 optical SPDIF 96 kHz/24 bits
External power supply
Input: 100-240 V ~60/50 Hz, 0.5A
Output : 12 V DC, 1A
Power consumption
(with no USb item connected)
2.2W
Available USb power supply 5 V / 800 mA
Useable temperature range +5 °C to +35 °C
Storage temperature -5 °C to +40 °C
Useable humidity range 40 % to 75 %
Network:
10/100Mb Ethernet
MAC & PHY
Wireless LAN 802.11b/g/n
WPS 2.0 security
Digital media renderer (compliant with DLNA 1.5)
Audio formats
(WiFi/RJ45)
WMA (WMA9, CBR,CBR, up to 320kbps)
PCM (16 bits-44.1kHz, 24 bits-44/48/96 kHz, .wav,
.aiff, .aif, .aifc files, HTTP streams)
AAC-LC (up to 320kbps), ALAC (.m4a)
FLAC (16 bits-44.1kHz, 24 bits- 44/48/96 kHz)
Dimensions (h x l x p) 4 x 23.1 x 13.6 cm - 1.6 x 9.1 x 5.4 in
Weight 0.5 kg - 1.1 lb
By following the above information, your Stream Source system is now properly set up and we hope you will enjoy your speaker system for many
years. We receive letters every day from customers expressing the ever growing satisfaction and musical emotion they have been getting with our
speakers over the years. These letters are our first motivation.
