Liste des Fonctions du Protocole RS232
Débit en bauds : 9600
Bits de Données : 8
Parité : Aucun
Bits d’Arrêt : 1
Contrôle de Flux : Aucun
UART16550 FIFO : Désactiver
Retour Projecteur (Avec succès) : P
Retour Projecteur (Échec) : F
XX=00-99, ID du projecteur,
XX=00 pour tous les projecteurs
Il y a un <CR> après toutes les commandes ASCII.
0D est le code HEX correspondant à <CR> en code
ASCII.
Optoma Data and HT Projectors
HD91/HD90
Baud Rate
9600
Data Bits
8
Parity
None
Stop Bits
1
Flow Control
None
UART16550 FIFO
Disable
~
X
X
X
X
X
n
CR
space
variable
carriage return
ASCII
Pass
Fail
Power
On/Off
n=1/n=0 & 2
~XX00 n
P
F
Re-sync
~XX01 n
P
F
HDMI 1
n=1
~XX12 n
P
VGA
n=5
VGA Component
n=8
Video
n=10
Component RCA
n=14
HDMI 2
n=15
Cinema
n=1
~XX20 n
P
F
Film
n=11
Bright
n=2
n=3
Reference
n=4
User
n=5
ISF Day
n=7
ISF Night
n=8
3D
n=9
Brightness
n= -50 - +50
~XX21 n
P
F
Contrast
n= -50 - +50
~XX22 n
P
F
Sharpness
n= 0 - +15
~XX23 n
P
F
Tint
n= -50 - +50
~XX44 n
P
F
Color
n= -50 - +50
~XX45 n
P
F
Red Gain
n= -50 - +50
~XX24 n
Green Gain
n= -50 - +50
~XX25 n
Blue Gain
n= -50 - +50
~XX26 n
Red Bias
n= -50 - +50
~XX27 n
Green Bias
n= -50 - +50
~XX28 n
Blue Bias
n= -50 - +50
~XX29 n
Reset
n=1
~XX33 n
D50
n=1
~XX210 n
D65
n=2
~XX210 n
D75
n=4
~XX210 n
D83
n=5
~XX210 n
D93
n=6
~XX210 n
Native
n=7
~XX210 n
Native
n=1
~XX211 n
Adobe
n=6
~XX211 n
DLP Cinema
n=2
~XX211 n
HDTV
n=3
~XX211 n
SMPT-C
n=5
~XX211 n
Red
n=1
~XX212 n
Green
n=2
~XX212 n
Blue
n=3
~XX212 n
Cyan
n=4
~XX212 n
Yellow
n=5
~XX212 n
Magenta
n=6
~XX212 n
x offset
-50 ~ 50
n= -50 - +50
~XX213 n
y offset
-50 ~ 50
n= -50 - +50
~XX214 n
Brightness
-50 ~ 50
n= -50 - +50
~XX217 n
Reset
n=1
~XX215 n
Film
n=1
~XX35 n
P
F
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX182 n
Offset
n=-5 - +5
~XX183 n
Reset
n=1
~XX206 n
Video
n=2
~XX35 n
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX184 n
Offset
n=-5 - +5
~XX185 n
Reset
n=1
~XX207 n
Graphics
n=3
~XX35 n
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX186 n
Offset
n=-5 - +5
~XX187 n
Reset
n=1
~XX208 n
Standard
n=4
~XX35 n
Curve Type
Film/Video/Graphics/1.8
/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.6
n=-5 - +6
~XX188 n
Offset
n=-5 - +5
~XX189 n
Reset
n=1
~XX209 n
Auto
n=1
~XX37 n
P
F
RGB (0-255)*
* RGB (0-255) supports when HDMI is detected
n=2
RGB(16 - 235)*
*RGB(16 - 235)supports when HDMI is detected
n=4
YUV
n=3
Noise Reduction
n= 0 - 10
~XX196 n
P
F
PureMotion
OFF
n=0
~XX190 n
LOW
n=1
~XX190 n
MED
n=2
~XX190 n
HIGH
n=3
~XX190 n
UltraDetail
OFF
n=0
~XX41 n
ON
n=1
~XX41 n
HD+
n=2
~XX41 n
PureColor
OFF
n=0
~XX42 n
1
n=1
~XX42 n
2
n=2
~XX42 n
3
n=3
~XX42 n
4
n=4
~XX42 n
5
n=5
~XX42 n
PureEngine Demo
OFF
n=0
~XX197 n
H Split
n=1
P
F
V Split
n=2
P
F
Power
100%/95%/90%/85%/
80%/75%/70%/65%/
60%/50%
n=0/n=1/n=2/n=3/n=4
/n=5/n=6/n=7/n=8/n=9
~XX326 n
P
F
DynamicBlack 1
n=1
P
F
DynamicBlack 2
n=2
P
F
DynamicBlack 3
n=3
P
F
4:3
n=1
~XX60 n
P
F
16:9
n=2
LBX
n=5
Native
n=6
Auto235
n=8
Auto235_Subtitle
n=11
SuperWide
n=9
Edge masking
n=0-5
~XX61 n
P
F
~XX191 n
D
IS
P
LA
Y
Don't support when Anamorphic lens is fixed
Don't support when Anamorphic lens is motored or fixed
LED Brightness
Supportingit When Anamorphic lens is fixed or motor
Don't support when Anamorphic lens is motored or fixed
Projector ID
Command ID
Function
Direct Source Commands
Color Space
Advanced
Color Gamut
PureEngine
CMS
Gamma
IM
A
G
E
RGB Gain/Bias
Color Temperature
Display Mode
Format
Color Settings
