Page 58: Annexes, 58 français, 1optoma v1 command table
58
Français
Annexes
Baud Rate : 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control : None
UART16550 FIFO: Disable
Projector Return (Pass): P
Projector Return (Fail): F
XX=00-99, projector's ID,
XX=00 is for all projectors
1
Optoma V1 Command Table.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Baud Rate : 9600
Note : There is a <CR> after all ASCII commands
Data Bits: 8
0D is the HEX code for <CR> in ASCII code
Parity: None
Stop Bits: 1
Flow Control : None
UART16550 FIFO: Disable
Projector Return (Pass): P
Projector Return (Fail): F
XX=01Į99, projector's ID, XX=00 is for all projectors
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND to projector
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code
Function
Description
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX00 1
7E 30 30 30 30 20 31 0D
Power ON
~XX00 0
7E 30 30 30 30 20 30 0D
Power OFF
(0/2 for backward compatible)
~XX00 1 ~nnnn 7E 30 30 30 30 20 31 20 a 0D Power ON with Password
~nnnn = ~0000 (a=7E 30 30 30 30) ~9999 (a=7E 39 39 39 39)
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ----------------------------------
~XX01 1
7E 30 30 30 31 20 31 0D
Resync
~XX02 1
7E 30 30 30 32 20 31 0D
AV Mute
On
~XX02 0
7E 30 30 30 32 20 30 0D
Off (0/2 for backward compatible)
~XX03 1
7E 30 30 30 33 20 31 0D
Mute
On
~XX03 0
7E 30 30 30 33 20 30 0D
Off (0/2 for backward compatible)
~XX04 1
7E 30 30 30 34 20 31 0D
Freeze
~XX04 0
7E 30 30 30 34 20 30 0D
Unfreeze
(0/2 for backward compatible)
~XX05 1
7E 30 30 30 35 20 31 0D
Zoom Plus
~XX06 1
7E 30 30 30 36 20 31 0D
Zoom Minus
~XX12 1
7E 30 30 31 32 20 31 0D
Direct Source Commands
HDMI
~XX12 5
7E 30 30 31 32 20 35 0D
VGA1
~XX12 6
7E 30 30 31 32 20 36 0D
VGA 2
~XX12 8
7E 30 30 31 32 20 38 0D
VGA1 Component
~XX12 9
7E 30 30 31 32 20 39 0D
S-Video
~XX12 10
7E 30 30 31 32 20 31 30 0D
Video
~XX12 13
7E 30 30 31 32 20 31 33 0D
VGA 2 Component
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ----------------------------------
~XX20 1
7E 30 30 32 30 20 31 0D
Display Mode
Presentation
~XX20 2
7E 30 30 32 30 20 32 0D
Bright
~XX20 3
7E 30 30 32 30 20 33 0D
Movie
~XX20 4
7E 30 30 32 30 20 34 0D
sRGB
~XX20 5
7E 30 30 32 30 20 35 0D
User
~XX20 7
7E 30 30 32 30 20 37 0D
Blackboard
~XX20 9
7E 30 30 32 30 20 39 0D
3D
~XX20 14
7E 30 30 32 30 20 31 34 0D
ISF Day
~XX20 15
7E 30 30 32 30 20 31 35 0D
ISF Night
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ----------------------------------
~XX21 n
7E 30 30 32 31 20 a 0D
Brightness
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
~XX22 n
7E 30 30 32 32 20 a 0D
Contrast
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
~XX23 n
7E 30 30 32 33 20 a 0D
Sharpness
n = 1 (a=31) ~ 15 (a=31 35)
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX24 n
7E 30 30 32 34 20 a 0D
Color Settings/White
Red
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
~XX25 n
7E 30 30 32 35 20 a 0D
Green
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
~XX26 n
7E 30 30 32 36 20 a 0D
Blue
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
~XX33 1
7E 30 30 33 33 20 31 0D
Reset
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ----------------------------------
~XX34 n
7E 30 30 33 34 20 a 0D
BrilliantColor
TM
n = 1 (a=30) ~ 10 (a=31 30)
~XX35 1
7E 30 30 33 35 20 31 0D
Gamma
Film
~XX35 2
7E 30 30 33 35 20 32 0D
Video
~XX35 3
7E 30 30 33 35 20 33 0D
Graphics
~XX35 4
7E 30 30 33 35 20 34 0D
Standard
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ----------------------------------
~XX36 1
7E 30 30 33 36 20 31 0D
Color Temp.
Warm
~XX36 2
7E 30 30 33 36 20 32 0D
Medium
~XX36 3
7E 30 30 33 36 20 33 0D
Cold
~XX37 1
7E 30 30 33 37 20 31 0D
Color Space
Auto
~XX37 2
7E 30 30 33 37 20 32 0D
RGB\RGB(0-255)
~XX37 3
7E 30 30 33 37 20 33 0D
YUV
~XX37 4
7E 30 30 33 37 20 34 0D
RGB(16-235)
~XX73 n
7E 30 30 37 33 20 a 0D
Signal
Frequency
n = -5 (a=2D 35) ~ 5 (a=35) By signal
~XX91 n
7E 30 30 39 31 20 a 0D
Automatic
n = 0 disable; n = 1 enable
~XX74 n
7E 30 30 37 34 20 a 0D
Phase
n = 0 (a=30) ~ 31 (a=33 31) By signal
~XX75 n
7E 30 30 37 35 20 a 0D
H. Position
n = -5 (a=2D 35) ~ 5 (a=35) By timing
~XX76 n
7E 30 30 37 36 20 a 0D
V. Position
n = -5 (a=2D 35) ~ 5 (a=35) By timing
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ----------------------------------
Liste des Fonctions du Protocole RS232
1. Chaque commande
ASCII est suivie d’un
<CR>.
2. 0D est le code HEX
pour <CR> en code
ASCII.
