FR-60
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND from projector automatically
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector
Return
Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
when Standby/Warming/Cooling/Out of
Range/Lamp fail/Fan Lock/Over Temperature/
Lamp Hours Running Out/Cover Open
INFOn
n : 0/1/2/3/4/6/7/8/ =
Standby/Warming/Cooling/Out
of Range/Lamp fail/Fan
Lock/Over Temperature/Lamp
Hours Running Out/Cover
Open
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector
Return
Description
~XX121 1
7E 30 30 31 32 31 20 31 0D Input Source Commands
OKn
n: 0/1/2/3/4/5=
None/VGA1/VGA2/Video/S-
Video/HDMI
~XX122 1
7E 30 30 31 32 32 20 31 0D Software Version
OKdddd
dddd: FW version
~XX123 1
7E 30 30 31 32 33 20 31 0D Display Mode
OKn
n : 0/1/2/3/4/5/6/7/
None/Presentation/Bright/Movie/sRGB/User/Blackboard./3D
~XX124 1
7E 30 30 31 32 34 20 31 0D Power State
OKn
n : 0/1 = Off/On
~XX125 1
7E 30 30 31 32 35 20 31 0D Brightness
OKn
~XX126 1
7E 30 30 31 32 36 20 31 0D Contrast
OKn
~XX127 1 7E 30 30 31 32 37 20 31 0D Aspect Ratio OKn
(WXGA) n: 0/1/2/3/4 = 4:3/16:9 or
16:10/LBX/Native/AUTO
(SVGA/XGA) n: 0/1/2/3/4 =
4:3/16:9/Native/AUTO
*16:9 or 16:10 depend on Screen Type setting
~XX128 1
7E 30 30 31 32 38 20 31 0D Color Temperature
OKn
n : 0/1/2 = Warm/Medium/Cold
~XX129 1
7E 30 30 31 32 39 20 31 0D Projection Mode
OKn
n : 0/1/2/3 = Front-Desktop/ Rear-
Desktop/ Front-Ceiling/ Rear-Ceiling
~XX150 1
7E 30 30 31 35 30 20 31 0D Information
OKabbbbccdddde
a : 0/1 = Off/On
bbbb: LampHour
cc: source
00/01/02/03/04/05/ = None/VGA1/VGA2/Video/S-Video/HDMI
dddd:
FW
version
e : Display mode 0/1/2/3/4/5/6/7
None/Presentation/Bright/Movie/sRGB/User/
Blackboard/3D
~XX151 1
7E 30 30 31 35 31 20 31 0D Model name
OKn
n:1/2/3=
SVGA/ XGA/ WXGA
~XX108 1
7E 30 30 31 30 38 20 31 0D Lamp Hours
OKbbbb
bbbb: LampHour
~XX108 2 7E 30 30 31 30 38 20 31 0D Cumulative Lamp Hours OKbbbbb
bbbbb: (5 digits) Total Lamp Hours
~XX321 1 7E 30 30 33 32 31 20 31 0D Filter Usage Hours OKbbbb bbbb: Filter Usage Hours
