Fr-85 – Optoma EH501 Manuel d'utilisation
Page 85
FR-85
~XX140 18
7E 30 30 31 34 30 20 31 38 0D
Volume +
~XX140 19
7E 30 30 31 34 30 20 31 39 0D
Brightness
~XX140 20
7E 30 30 31 34 30 20 32 30 0D
Menu
~XX140 21
7E 30 30 31 34 30 20 32 31 0D
Zoom
~XX140 47
7E 30 30 31 34 30 20 34 37 0D
Source
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND from projector automatically
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector
Return
Description
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
when Standby/Warming/Cooling/Out of
Range/Lamp fail/Fan Lock/Over Temperature/
Lamp Hours Running Out/Cover Open
INFOn
n : 0/1/2/3/4/6/7/8/ = Standby/Warming/Cooling/Out of
Range/Lamp fail/Fan Lock/Over Temperature/Lamp Hours
Running Out/Cover Open
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector
Return
Description
~XX121 1
7E 30 30 31 32 31 20 31 0D Input Source Commands
OKn
n: 0/1/2/3/4/5/6/7/8/9 =
None/VGA1/VGA2/Video/S-Video/HDMI/DVI/Flash
drive/Network display/USB display
~XX122 1
7E 30 30 31 32 32 20 31 0D Sofware Version
OKdddd
dddd: FW version
~XX123 1
7E 30 30 31 32 33 20 31 0D Display Mode
OKn
n : 0/1/2/3/4/5/6/7/8/
None/Presentation/Bright/Movie/sRGB/User/Blackboard/DICOM SIM./3D
~XX124 1
7E 30 30 31 32 34 20 31 0D Power State
OKn
n : 0/1 = Off/On
~XX125 1
7E 30 30 31 32 35 20 31 0D Brightness
OKn
~XX126 1
7E 30 30 31 32 36 20 31 0D Contrast
OKn
~XX127 1
7E 30 30 31 32 37 20 31 0D Format
Okn
(W501) n: 0/1/2/3/4/5 =
4:3/16:9/16:10/LBX/Native/AUTO
(EH501) n: 0/1/2/3/4 =4:3/16:9/LBX/Native/AUTO
(X501) n: 0/1/2/3 =4:3/16:9/Native/AUTO
*16:9 or 16:10 depend on Screen Type setting
~XX128 1
7E 30 30 31 32 38 20 31 0D Color Temperature
OKn
n : 0/1/2 = Warm/Medium/Cold
~XX129 1
7E 30 30 31 32 39 20 31 0D Projection Mode
OKn
n : 0/1/2/3 = Front-Desktop/ Rear-Desktop/ Front-Ceiling/
Rear-Ceiling
~XX150 1
7E 30 30 31 35 30 20 31 0D Information
OKabbbbccdddde
a : 0/1 = Off/On
bbbb:
LampHour
cc: source
00/01/02/03/04/05/06/07/08/09 =
None/VGA1/VGA2/Video/S-Video/HDMI/DVI/Flash Drive/Network display/USBdisplay
dddd: FW version
e : Display mode 0/1/2/3/4/5/6/7/8/
None/Presentation/Bright/Movie/sRGB/User/
Blackboard/ DICOM SIM /3D
~XX151 1
7E 30 30 31 35 31 20 31 0D Model name
OKn
n:1/2/3=X501/W501/EH501
~XX108 1
7E 30 30 31 30 38 20 31 0D Lamp Hours
OKbbbb
bbbb: LampHour
~XX108 2
7E 30 30 31 30 38 20 31 0D
Cumulative Lamp Hours
OKbbbbb
bbbbb: (5 digits) Total Lamp
Hours
~XX321 1
7E 30 30 33 32 31 20 31 0D
Filter Usage Hours OKbbbb
bbbb: Filter Usage Hours
~XX87 1
7E 30 30 38 37 20 31 0D
Network Status
Okn
n=0/1 Disconnected/Connected
~XX87 3
7E 30 30 38 37 20 33 0D
IP Address
Okaaa_bbb_ccc_ddd
~XX451 1
7E 30 30 34 35 31 20 31 0D WLAN Network Status
Okn n=0/1 Disconnected/Connected
~XX451 2
7E 30 30 34 35 31 20 32 0D WLAN IP Address
Okaaa_bbb_ccc_ddd
~XX451 3
7E 30 30 34 35 31 20 33 0D SSID
Okaaaaaaaaaaaaaaaaaaaa
