Annexes
SEND to emulate Remote
~XX140 10
7E 30 30 31 34 30 20 31 30 0D
Up
~XX140 11
7E 30 30 31 34 30 20 31 31 0D
Left
~XX140 12
7E 30 30 31 34 30 20 31 32 0D
Enter (for projection MENU)
~XX140 13
7E 30 30 31 34 30 20 31 33 0D
Right
~XX140 14
7E 30 30 31 34 30 20 31 34 0D
Down
~XX140 15
7E 30 30 31 34 30 20 31 35 0D
Keystone +
~XX140 16
7E 30 30 31 34 30 20 31 36 0D
Keystone –
~XX140 17
7E 30 30 31 34 30 20 31 37 0D
Volume –
~XX140 18
7E 30 30 31 34 30 20 31 38 0D
Volume +
~XX140 19
7E 30 30 31 34 30 20 31 39 0D
Brightness
~XX140 20
7E 30 30 31 34 30 20 32 30 0D
Menu
~XX140 21
7E 30 30 31 34 30 20 32 31 0D
Zoom
~XX140 28
7E 30 30 31 34 30 20 32 38 0D
Contrast
~XX140 47
7E 30 30 31 34 30 20 34 37 0D
Source
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND from projector automatically
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector Return
Description
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
when Standby/Warming/Cooling/Out of
Range/Lamp fail/Fan Lock/Over Temperature/
Lamp Hours Running Out/Cover Open
INFOn n : 0/1/2/3/4/6/7/8/ =
Standby/Warming/Cooling/Out
of Range/Lamp fail/Fan
Lock/Over Temperature/Lamp Hours Running Out/Cover Open
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector Return
Description
~XX121 1
7E 30 30 31 32 31 20 31 0D Input Source Commands
OKn
n: 0/2/3/4/5/7/8/15 =
None/VGA1/VGA2/Video/S-Video/HDMI1/HDMI2/DisplayPort
~XX122 1
7E 30 30 31 32 32 20 31 0D Sofware Version
OKdddd
dddd: FW version
~XX123 1
7E 30 30 31 32 33 20 31 0D Display Mode
OKn
n : 0/1/2/3/4/5/6/7/8/
None/Presentation/Bright/Movie/sRGB/User/Blackboard/DICOM SIM./3D
~XX124 1
7E 30 30 31 32 34 20 31 0D Power State
OKn
n : 0/1 = Off/On
~XX125 1
7E 30 30 31 32 35 20 31 0D Brightness
OKn
~XX126 1
7E 30 30 31 32 36 20 31 0D Contrast
OKn
~XX127 1
7E 30 30 31 32 37 20 31 0D Format OKn
n: 0/1/2/3/4 =
4:3/16:9/LBX/Native/AUTO
––~XX128 1
7E 30 30 31 32 38 20 31 0D Color Temperature
OKn
n :3/0/1/2 = Warm/Standard/Cool/Cold
~XX129 1
7E 30 30 31 32 39 20 31 0D Projection Mode
OKn
n : 0/1/2/3 = Front-Desktop/ Rear-Desktop/ Front-Ceiling/ Rear-Ceiling
~XX150 1
7E 30 30 31 35 30 20 31 0D Information
OKabbbbccdddde
a : 0/1 = Off/On
bbbb: LampHour
cc: source 00/02/03/04/05/07/08/15 =
None/VGA1/VGA2/Video/S-Video/HDMI1/HDMI2/DisplayPort
dddd: FW version
e : Display mode 0/1/2/3/4/5/6/7/8/
None/Presentation/Bright/Movie/sRGB/User/
Blackboard/ DICOM SIM /3D
~XX151 1
7E 30 30 31 35 31 20 31 0D Model name
OKn
n:1/2=X600/EH500
~XX108 1
7E 30 30 31 30 38 20 31 0D Lamp Hours
OKbbbb
bbbb: LampHour
~XX108 2
7E 30 30 31 30 38 20 31 0D Cumulative Lamp Hours OKbbbbb bbbbb: (5 digits) Total Lamp Hours–––
~XX87 1 7E 30 30 38 37 20 31 0D Network Status Okn n=0/1
Disconnected/Connected
~XX87 3 7E 30 30 38 37 20 33 0D IP Address Okaaa_bbb_ccc_ddd
