8
PL-8 C OWNER’S MANUAL
SPECIFICATIONS
CURRENT RATING:
15 amps
OPERATING VOLTAGE:
90 to 139 VAC
OVER VOLTAGE SHUTDOWN:
140 VAC typically
SPIKE PROTECTION MODES:
Line to neutral, zero ground leakage
SPIKE CLAMPING VOLTAGE:
188 VAC peak @ 3,000 Amps, 133 VAC RMS
RESPONSE TIME:
1 nanosecond
MAXIMUM SURGE CURRENT:
6,500 amps
NOISE ATTENUATION:
10 dB @ 10 kHz, 40 dB @ 100 kHz, 50dB @ 500 kHz
Linear attenuation curve from 0.05 - 100 Ohms line impedance
DIMENSIONS:
1.75” H x 19” W x 10.5” D.
WEIGHT:
11 lbs. (5 kg.)
CONSTRUCTION:
Steel chassis, .120” brushed and black anodized aluminum front panel; glass epoxy printed circuit boards
POWER CONSUMPTION:
10 VA
SAFETY AGENCY LISTING:
TUV
