Calls
This chapter explains the operations to receive, respond to,
make, and stop calls.
You can select a subscriber alias or ID, or group alias or ID
after you have selected a channel by using one of these
features:
Programmed One Touch Access Button
This method is used for Group, Private, and Phone
Calls only.
You can only have one ID assigned to a One Touch
Access button with a short or long programmable
button press.
Group Calls
Your radio must be configured as part of a group to receive
a call from or make a call to the group of users.
Responding to Group Calls
To receive a call from a group of users, your radio must be
configured as part of that group. Follow the procedure to
respond to Group Calls on your radio.
When you receive a Group Call:
• The green LED blinks.
• Your radio unmutes and the incoming call sounds
through the speaker.
1 Do one of the following:
• If the Channel Free Indication feature is
enabled, you hear a short alert tone the moment
the transmitting radio releases the
PTT button,
indicating the channel is free for you to respond.
Press the
PTT button to respond to the call.
• If the Voice Interrupt feature is enabled, press
the PTT button to interrupt the audio from the
transmitting radio and free the channel for you to
respond.
The green LED lights up.
2 Do one of the following:
• Wait for the Talk Permit Tone to end and speak
clearly into the microphone if enabled.
• Wait for the PTT Sidetone to end and speak
clearly into the microphone if enabled.
English
27
