33
ENGLISH
17 [Channel] Skip/Add (Command: m b)
► To skip current channel for next time.
Transmission
(m)(b)( )([Set ID])( )(Data)(Cr)
Data 00: Del(ATSC,ISDB)/Skip(DVB)
Data 01: Add
Ack
(b)( )([Set ID])( )(OK/NG)(Data)(x)
* Set the saved channel status to del(ATSC, ISDB)/
skip(DVB) or add.
18 Key (Command: m c)
► To send IR remote key code.
Transmission
(m)(c)( )([Set ID])( )(Data)(Cr)
Data: Key code - page 22
Ack
(c)( )([Set ID])( )(OK/NG)(Data)(x)
19 Control [Backlight] (Command: m g)
► To control the backlight.
Transmission
(m)(g)( )([Set ID])( )(Data)(Cr)
Data Min: 00 to Max: 64
Ack
(g)( )([Set ID])( )(OK/NG)(Data)(x)
20 Input select (Command: x b) (Main Picture Input)
► To select input source for main picture.
Transmission
(x)(b)( )([Set ID])( )(Data)(Cr)
Data 00: DTV
Data 01: CADTV
Data 02: Satellite DTV ISDB-BS (Japan)
Data 03: ISDB-CS1 (Japan)
Data 04: ISDB-CS2 (Japan)
Data 10: ATV
Data 11: CATV
Data 20: AV or AV1
Data 21: AV2
Data 40: Component1
Data 41: Component2
Data 60: RGB
Data 90: HDMI1
Data 91: HDMI2
Data 92: HDMI3
Data 93: HDMI4
Ack
(b)( )([Set ID])( )(OK/NG)(Data)(x)
* This function depends on model and signal.
