Airpulse A300 Bluetooth Speaker System (Pair) - Manuel (Page 10)

Bluetooth Input Mode
* Effective Bluetooth connection distance is within 10 meters.
* The Bluetooth of A300 can only be searched and connected in Bluetooth input. The existing
Bluetooth connection will be disconnected once the speaker is switched into other audio inputs.
When switched to Bluetooth input, the speaker will try to connect to the Bluetooth device
connected last time .
* To disconnect Bluetooth, press and hold the “ ” button on the remote control for above 2 seconds.
* To enjoy all Bluetooth functions please ensure your audio device has A2DP and AVRCP profiles.
* When connected to this product, Bluetooth connectivity and functions may be different
between different Bluetooth devices,depending on software settings of Bluetooth devices .
1. Press the “ ” button on the remote control or press the “VOLUME / INPUT” button
on the rear panel of the active speaker to select Bluetooth input mode, LED indicator
on the active speaker will display “ ”.
2. Set your Bluetooth device to search for and connect to “AIRPULSE A300”; pin
code for connection is “0000” if needed.
Operations may be different between different devices, please refer to the operational
instructions attached with the devices.
AIRPULSE A300
Bluetooth
3. Play music on the connected Bluetooth device, press the “+/-” button on the remote
control or press the “VOLUME / INPUT” button on the rear panel of the active speaker
to adjust volume to a desired level.
Tweeter: Horn Loaded Ribbon Tweeter
Mid-Woofer: 6.5inch Aluminum Cone Underhung Design Neodymium
Power Mid-Woofer
Amplifier System: Digital Amplifier with Xmos Processor
Power Output: L/R (Treble):10W+10W,
L/R (Woofer): 70W+70W
Frequency Range: 40Hz-40KHz
Signal-Noise Ratio: L/R≥90dB(A)
Input Mode: AUX, Balance Input, USB, Optical, Coaxial, Bluetooth.
The USB, Optical and Coaxial inputs support up to 192KHz
input sample rate
I nput Sensitivity: AUX: 700±50mV,
Balance: 1150±50mV,
USB: 550±50mFFs,
Optical: 500±50mFFs
Coaxial: 500±50mFFs,
Bluetooth: 500±50mFFs
Mains Voltage: 100-240V AC 50/60Hz
Cabinet Size (WxHxD): 225 x 385 x 340 (mm)
Net Weight: 24 Kg (53 Pounds) / Set
Specifications/statement
NOTICE: For the need of technical improvement and system upgrade, information
contained herein may be subject to change from time to time without prior notice.
17 18
AUX BAL
USB
OPT COAX
4. In Bluetooth mode, press the “ ” button on the remote control can skip to
previous/next track, and press the “ ” button to pause/play songs.
Or
IN P U T / V O LU M E
IN P U T / V O LU M E
AUX BAL
USB
OPT COAX
IN P U T / V O LU M E
IN P U T / V O LU M E
Or
English English
Qualcomm aptX is a product of Qualcomm Technologies, Inc. and/or its subsidiaries.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other
countries. aptX is a trademark of Qualcomm Technologies International, Ltd., registered in the
United States and other countries.
