StarTech.com NETRS2322P 2-Port Serial-to-IP Ethernet Device Server - Manuel (Page 2)

The RS232 device server supports Telnet (an operating system independent communication protocol), so it can
be integrated into mixed OS environments (Windows, Mac, Linux®). Plus, it supports VCOM, TCP, ICMP, IP,
TCP, UDP, DHCP, and BOOTP protocols.
The NETRS2322P is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applicazioni
Integrate into industrial, warehouse, or factory environments that are subject to harsh conditions and
large temperature variances
Fasten to a wall or desk, using the integrated mounting brackets
Ideal for settings where critical equipment requires continuous power, with two power inputs
Use with CNC machinery and process control equipment, as well as environmental control, and point-of-
sale (POS) devices
Caratteristiche
Two RS232 (DB9) serial ports, integrated into a durable, metal housing that’s ideal for industrial
environments
Built-in mounting brackets let you easily install the device server to a wall or surface
Redundant power input using the provided power adapter, or 9~36V DC terminal block input
Extended operating temperature range — 0°C to 85°C (32°F to 185°F)
Up to 460.8Kbps serial baud rate
Remote management and customization using the provided Windows based VCOM software or the Web
interface
Supports Telnet, ICMP, IP, TCP, UDP, DHCP and BOOTP protocols
15kV Air and 8kV contact ESD (Electrostatic Discharge) Protection
10/100Mbps RJ45 port that supports IEEE 802.3 (10BASE-T) and IEEE 802.3u (100BASE-TX) protocols
