Description of your dishwasher
31
START/STOP: Press
this button to switch
your dishwasher on.
START/CANCEL:
Pressing this button
starts this pro-
gramme. Holding
the button pressed
down for 2 seconds
cancels the
Programme.
DELAYED START:
Press this button to
delay the end of
the programme by
3 or 6 hours.
PROGRAMME
BUTTONS: Press one of
these buttons to select your
programme.
SALT LIGHT: This indi-
cates that there is no
regenerating salt.
RINSE AID LIGHT:
This indicates that
there is no rinse
aid.
The control strip in the top of the door can be seen
when you open the door
Description of your dishwasher
30
The above photograph of the machine with the lower basket removed
shows you all the main components described in these operating
instructions.
Regenerating
salt reservoir
Waste filters
Washing product
container
Rinsing agent
container
Lower sprinkling
arm
Information
plate (After-
Sales service
reference)
Drying valve
(depending on
the model)
Upper basket
Main filter
Anti-blocking
size wire
Control strip
(Described on the next
Your dishwasher is fitted with safety systems protecting you from flood-
ing:
The ANTI-OVERFLOW SYSTEM. This system automatically activates
the drain pump if the water in the tub reaches an abnormal level.
The ANTI-LEAK SYSTEM. This system cuts off the water supply if a
leak is detected under the machine.
The ANTI-BURSTING HOSE. This reinforced water supply hose is fit-
ted with a mechanism that cuts off the water supply directly at the tap
if a water leak occurs.
