1412002 PARTS LIST / LISTE DE PIECES
1412002 PRE-INSTALLED PARTS / PIECES PREINSTALLEES
P1 P2
x4 x2 x1
P3
Apron Corner Coin de Tablier Felt Pad Tampon Feutre
Mainframe Unité centrale Pusher Lanceur Round Puck Rondelle Ronde Goal But
3x14mm Screw 3x10mm Screw Vis 3x14mm Vis 3x10mm
Motor Moteur
