15 GB/IE
solar cell housing 1 with the help of a slot
screwdriver (see Fig. B).
3. Remove the fastening screw 6 of the
On / Off switch 5 , by using a small cross
head screwdriver. Carefully take out the
switch. Take care not to damage the cables
and cable connections (see Fig. C).
4. Exchange the old rechargeable battery 8 to
a new one. Take care to the correct polarity,
when inserting the new rechargeable battery.
The polarity is indicated in the battery com-
partment. The new rechargeable battery has
to have the same technical data like the old one.
5. Now again fasten the On / Off switch 5 and
close the battery compartment lid 7 . Slide
the On / Off switch 5 to the position ON.
6. Connect the solar cell housing 1 again to the
lamp shade 2 and then connect every part
of the solar lamp to each other (see Fig. D).
Charging the
rechargeable battery
Note that the solar garden light must be switched
on when the battery is charging.
