Telescopic Garden Shelving
Introduction
Congratulations! You have purchased a
high-quality product. Familiarise yourself
with the product prior to assembly. Care-
fully read the following assembly instructions and
safety advice. Only use the product as described
and for the indicated purpose. Keep the instructions
in a safe place, you might need them later. If you
pass the product on to anyone else, please ensure
that you also pass on all the documentation with it.
Intended use
The telescopic garden shelf is only intended for pri-
vate use for space-saving indoor storage of garden
tools. Any use other than previously mentioned or
any product modification is prohibited and can lead
to injuries and / or product damage. The manufac-
turer is not liable for damage caused by improper
use. The product is not intended for commercial use.
Technical Data
Dimensions: Approx. 65.5 x 250–300 x 32 cm
(w x h x d)
Total load up to 30 kg (static load)
Safety information
DANGER TO
LIFE AND RISK OF ACCIDENTS
FOR INFANTS AND CHILDREN!
Never leave children unattended with the pack-
aging material or the product. The packaging
material presents a suffocation hazard and
there is a risk of loss of life from strangulation.
Children frequently underestimate the dangers.
Please keep children away from the product at
all times. This product is not a toy.
Only suitable for light garden tools. Avoid
excessive and improper loads on the shelf.
When in doubt, refrain from excessive loads.
Before drilling, ensure that there are no gas or
water pipes or cables where you intend to drill.
Installation may only be carried out by experts.
It is essential that you take note of the wall
quality, as the included fittings are not suitable
for all types of wall. Enquire at dealers for the
screws and wall plugs suitable for the respec-
tive wall quality. The manufacturer accepts no
responsibility for an inappropriate wall plug
connection and any resulting damage.
Assembly
Assemble the product per Figure A–I.
Note (Fig. A): The setscrews self-tap the thread
into the plastic when screwed in. Position the head-
less screw
21
straight onto the hole and screw in
slowly.
Note (Fig. B): First slide the suspension devices
16
and hooks
17
over the shelf rod
4
before securing
the brackets
6
to the shelf rod
4
. The spacing
between the suspension devices
16
is adjustable in
width – depending on the size of the garden tools.
These are suitable for tools with wide edges, e.g.
rakes, shovels or hooks.
Note (Fig. C): Use a rubber mallet to firmly con-
nect the shelf rods
3
with the mounting bar
1
.
Only then attach the bracket
7
. Be sure the
bracket
7
snaps in between the two grooves on
the mounting bar
1
.
Note (Fig. F): Do not yet secure the top shelf of
the unit. This will be the last step (see note (Fig. I)).
Note (Fig. G): Screw the height adjustment
10
all the way in before securing.
Note (Fig. H): First secure the shelving unit to the
wall before securing to the ceiling.
Note (Fig. I): To clamp the telescopic pole into
place, loosen the headless screw
21
and extend
the inner pole
2
to the ceiling. Lock the inner
pole
2
by tightening the headless screw
21
.
Unscrew the height adjustment
10
until the shelf is
securely locked into place (pretension).
