5
1.2 Back side Buttons
1.3 Left Side of Frame
2. Installing & Replacing the Battery
Place the upside of the remote control down, press down on the ridged area of the
battery cover and pull towards you to remove the tray. Place one CR2025 lithium
button-cell battery on the tray with the positive “+”side facing you. Reinsert the tray
3. Getting Started
3.1 Put the digital photo frame with installing bracket on a flat position stability, then
plug one end of the AC adapter into a standard 100-120V AC electrical outlet
and the other end into the DC IN slot on the left side of the frame.
Note: The installing and standing method refer to "Stand Instruction".
3.2 Remove the protective film covering the LCD.
3.3 Remove the plastic battery insulator from the battery compartment and make sure
the remote control has a battery inside. Please refer to “Installing & Replacing
Battery” if you need a new battery.
3.4 Press the Power Button on the Remote Control to Switch On/Off.
1. Power on/off
2. Up
3. Vol +/Right
4. Play/Pause/OK
5. Vol -/ Left
6. Down
7. Menu
1. SD/MMC/MS Card
2. Earphone Jack
3. USB
4. Mini USB
5. DC in
