Remote Control
BATTERY INSTALLATION
- Before installation
Remove and discard the insulation tab.
-Replace battery for the remote control
1. Push and slide out the battery holder as Figure 1 below.
2. Replace the battery with a new CR2025 button cell with the polarity (+) side upward.
3. Slide into the battery holder.
Battery precautions
• Never recharge the batteries, apply heat to them or take them apart.
• Attention should be drawn to the environmental aspects of battery disposal.
• If the remote control is not going to be used for a long time, remove the battery
to avoid damage caused by battery leakage corrosion.
6
2
3
5
7
VOL+
FM SCAN
TUN-
M+ EQ
VOL-
BASS- BASS+
TREBLE- TREBLE+
TUN+
8
9
4
6
1
10
11
12
13
14
16
15
CLOCK
MODE
Button
on Button 6. EQ Butt
1.MODE
2. Standby Button 7. VOL- (Volume-) Button 13. VOL+ (Volume+) Button
5. M+ Button
10. Mute Button
16. TREBLE+ Button
11. TUN+ Button
12.
3. FM SCAN Button
8. BASS- Button
14. BASS+ Button
4. TUN - Button
9. TREBLE- Button
15. Play/Pause Button
shall not be exposed to excessive heat such as sunshine, fire or the like.
• Do not throw the batteries in fire!
•Battery
CLOCK
( Preset recall)
