— E-2 — — E-4 —
PREPARATIONS BEFORE USING
Battery Installation
1. Open Battery Compartment cover.
2. Insert 2 batteries (LR6, “AA” size, or equivalent)
in the correct polarity as indicated.(Batteries not included)
(Heavy duty batteries are recommended.)
3. Close the cover properly.
AC Power Adaptor
1. Plug the DC output of the adaptor to the DC Jack.
2. Connect the adaptor (4.5V/500mA) to a power outlet.(Adaptor not included)
Make sure the voltage is compatible.
DISC PLAYING
This CD player is designed to play the 8cm and 12cm compact disc without using
adaptor.
Hold Switch
Set the HOLD switch to “ON” position, all the buttons will be locked. Before
operation, be sure to set the switch to “OFF” position, for normal operation.
Getting Start
1. Insert the headphone/earphone plug to PHONE JACK.
2. Push the OPEN switch to right side, and then the door open, put a disc into the
CD compartment with label side upward.
3. Push the disc gently around the centre area until it clicks so that the disc fits
into the pivot.
(To remove the disc : Pick up the disc, holding the edge, while pressing the
pivot gently.)
4. Close the door and press the PLAY/PAUSE button once.
5. The Display will show the total number of tracks of the disc, then begin to play
the first track.
General Operation
Play/Pause Buttons — Press once to start playback in the original
order.
P r e s s a g a i n t o s t o p t h e d i s c p l a y
temporarily.
Stop Button — Press once to stop playback.
Press again to turn off power.
Skip / Search Buttons — Press once to skip to next track or
back to previous track .
— Press continuiously to search forward
or backward .
Various Playing Modes
MODE Button — There are 3 kind of function :
A. Repeat Play
During PLAY mode
•
Press the MODE button once to play single track repeatedly.
• The repeat indicator will appear in the display.
During PLAY mode
•
Press the MODE button twice to play the entire disc repeatedly.
• The repeat indicator will appear in the display.
NOTE - To cancel REPEAT simply press the MODE button until the repeat indicator
disappears.
B. Intro Scan
In STOP mode
•
Press the MODE button three times.
• The INTRO indicator will appear in the display.
• Press the PLAY button to play the first 10 seconds of each track on the disc.
NOTE - To cancel INTRO SCAN simply press the MODE button until the INTRO
indicator disappears.
C. Random Play
In STOP mode
•
Press the MODE button four times.
• The SHUF indicator will appear in the display.
• Press the PLAY button, all the tracks on a disc to be played in a random sequence.
NOTE - To cancel RANDOM PLAY simply press the MODE button until the SHUF
indicator disappears.
Program Play
1. Press the PROG button when the unit is in the stop mode until PGM show on the
display.
* The PGM indicator will appears on the display.
2. Press or to select the desired track.
3. Press the PROG button to enter the track into memory. The program numbers
which will be increment one step.
4. Repeat step 2 and 3 to program the order of more tracks can be programmed into
memory.
5. Press to start the program play.
6. To erase the program, simply press the STOP button to turn the power off.
— E-3 —
DIGITAL ANTI-SHOCK OPERATION
The digital ELECTRONIC SHOCK PROTECTION function uses semiconductor memory to
prevent the second from skipping when the unit is subjected to shocks and vibration during play.
When the PLAY/PAUSE button is pressed and the power turns on, the digital Electronic
Shock Protection function turns on automatically.
The display will show and the function is initialized, when shows in the display,
the data buffer is full.
It will give approximately 45 seconds of protection against interruption of sound output, if the
player is subjected to shocks of more than 45 seconds duration, some interruption of sound
output will occur, this is normal and to be expected, the sound will resume once the player
has stabilized from the shock.
To turn this function off, press ASP button once, the ESP indicator will disappear.
MAINTENANCE
Cleaning the Lens
If the lens becomes dusty, clean it with camera lens blower. Be careful not to scratch the
surface of the lens.
Cleaning the Cabinet
From time to time, clean the cabinet with a soft dry cloth. For more stubborn stains, slightly
moisten the cloth with water or a mild detergent solution. Never use benzene, alcohol or
other solvents as they may damage the finish of the cabinet.
SPECIFICATIONS
Output Power : 20 mW (32 )
Freq. Range : 100 ~ 20000 Hz
Power : DC 4.5V external and size “AA” batteries, UM-3, HP-7, R6,1.5V x 2
Dimensions : 142mm(W) x 142mm(D) x 31mm(H)
** For improvement purposes, specification and design are subject to change without
notice. **
