Ypbpr connection (component) (component), Av connection, Dvd or vcr back – Curtis LCDVD152AC Manuel d'utilisation
Page 9
RF
RF
-
IDE
SV
O
-I
DE
S
VO
L
R
PHONE
Pb
Pr
Y
8
YPbPr
Connection
(Component)
(Component)
Connect the YPbPr output of the DVD or VCR to the YPbPr input on the set. The picture quality is
improved; compared to connecting a regular VCR to the video input. Connect the Audio output of
the DVD or VCR to the Audio input jacks on the set using the RCA cable.
Match the jacks colors :Y is green,Pb is blue,Pr is red,Audio left is white and Audio right in red.
Select component input source with using the SOURCE button on the remote control.
DVD or VCR
DVD or VCR
DVD or VCR Back
DVD or VCR Back
YPbPr cable
YPbPr cable
AUDIO cable
AUDIO cable
Connect the VIDEO and AUDIO output jack of the DVD or VCR to the VIDEO jacks on the set using
the RCA cable. Match the jack colors: Video is yellow, Audio left is white, and Audio right is red.
Select the AV input source with using the SOURCE button on the remote control.
AV Connection
1
Video Cable
Video Cable
TV Back
TV Back
VIDEO L R
VIDEO L R
DVD or VCR
DVD or VCR
DVD or VCR Back
DVD or VCR Back
VGA
(PC
)
VGA
(PC
)
-I
D
E
SV
O
-I
D
E
S
VO
L
R
Pb
Pr
Y
PC D
I
AU
O
I
VD
E
O
I
VD
E
O
I
V
DEOI
VD
E
O
Y
Pb Pr
L
R
(Component
)
(Component
)
(Component
)
(Component
)
