ESPRIT Ez 20
Open the box and remove all staples, then carefully take the speaker out of the box. When
unpacking, if you notice any defects on any of the drivers or the cabinet, you should contact
your dealer.
Before disposing the packaging, check that nothing is left inside.
Unpacking
Connections
For optimal sound reproduction, we suggest that you choose a loudspeaker cable of high
quality to connect your amplifier to your TRIANGLE loudspeakers.TRIANGLE’s high defini-
tion OFC cable will guarantee an excellent result. You should use cables of the same length
for the left and right channels and take special care to respect the + and - polarity for each
channel.
ATTENTION:
If one of the speakers is placed next to a television, colour settings may be affected by the
speaker’s magnetism. Keep a minimum distance of 1 m.
Bi-amplification and bi-wiring for Antal Ez.
For those wishing to improve their listening system further, it is possible to use bi-amplifi-
cation or bi-wiring.
With bi-amplification, interference between the woofers and other drivers is totally elimina-
ted, as each one is driven by its own amplifier. It is compulsory to use identical amplifiers to
conserve the uniformity of the loudspeaker.
To do this, remove the terminal jumpers and use two stereo amplifiers. On the speakers, the
upper terminals are the signal inputs for midrange and treble. The lower terminals are the
signal inputs for bass. Use one amplifier to feed the bass, and the second for the midrange
and treble (see the diagram below).
Instead of two amplifiers, you can use a single amplifier if it is equipped with two sets of
speakers A and B. Both sets should be selected. This is bi-wiring and not bi-amplification.
A
B
