Sansui SLED5015 - Manuel (Page 12)

1
3
2
4
Install and Connect TV
TV ANT FM ANT
TV signal output
Set your TV
1.Put your TV in a place that can bear the
weight of the TV.
To avoid danger, please do not assemble
the TV near water or extreme heat(such
as a furnace, light source,or candle.)
Do not block the ventilation on the back
of the TV.
Connect antenna and power
2.Connect the antenna cable to the RF
connection on the back of the TV.
Plug the TV into the wall power outlet(
AC120~ 60Hz).
1
3
Turn on the TV
3.While in standby mode the power indication
light will be red.Press the power button on
the TV or remote control.The light will change
to green.
Note:
Picture for reference purposes only.
2
TV Stand Installation Instructions
TV Stand Installation Instructions
1. Open the carton and remove the TV,
accessories, and base.
2. To avoid injury to the TV, place the TV
face down on a firm surface, covered
with a soft cloth. Attach the neck to the
TV with the supplied screws.
3. Attach the base to the neck with the
supplied screws.
4. Note: Insufficient tightening or incorrect
installation of the stand will not support
your unit correctly, and could result in
damage or injury from a tip-over.
