13
WIRING DIAGRAM
S40
Junction Box
L N
Gnd
BK WH
BR (Line)
YL (Min. Voltage)
GY (Lamps)
RD (Med. Voltage)
BK (Max. Voltage)
BR
BU
YL
WH
RD
BK
YL
YL
BK
RD
BU
WH
WH
BU
WH
BR
BK
Mechanical Push Buttons
(4 buttons 3 speeds)
SE12DA
12.5uF
Max. Voltage
High Voltage
Medium Voltage
Minimum Voltage
Common
YL/GN
YL/GN
YL
GY
BK
WH
RD
BU
Motor
Characteristics
Power Supply
Frequency
Power Absorption 240 Watts
120 VAC
60 Hz
Motor Resistance
(Ohms)
Blue - Black
Blue - Gray
Blue - Red
Blue - White
Room Temp.
28.8 ±10%
30.3 ±10%
37.7 ±10%
45.1 ±10%
73.4˚F (23˚C)
Motor
Chassis
Switch Operation
POSITION FUNCTION
Off
Lamps
Low Speed
Medium
Speed
High Speed
No Connection
Brown - Gray
(L - 1)
Brown - Yellow
(L - 2)
Brown - Red
(L - 3)
Brown - Black
(L - 4)
BU
WH
YL
YL
BR
YL
