LEI Electronics TXTCONKIT2 - Manuel

TXTCONKIT2
DUAL VOLTAGE
CONVERTER KIT
User’s Guide
1. For use when traveling to other countries that use
220/240VAC.
Note: Not for use in North America
2. Converts the voltage of your small electronics safely
in other countries
3. Kit includes five adapter plugs: 0-50 watts (for electronics)
and 50-1600 watts (for heating products)
INSTRUCTIONS
1. Select proper wattage setting.
Check the appliance name plate for appropriate wattage. Then set the selector switch on the converter to 50W or 1600W setting.
If the wattage is not provided on appliance name plate it can be calculated if you know the amperage by using the following formula,
W wattage = V voltage x I amperage (mA or A)
i. Set the converter to 50W when using with battery chargers, electric toothbrushes, shavers, contact lens sterilizers, etc., that do not exceed 50 Watts.
ii. Set the converter to 1600 Watts for use with clothes steamers, hair dryers, travel irons, curling irons, food/bottle warmers, etc.
2. If adapter plug is necessary, attach adapter plug to converter before attempting to plug converter into the wall outlet.
3. Insert converter into wall outlet.
Note: Must insert converter into the appropriate adapter plug BEFORE plugging the converter into the wall outlet.
4. Plug appliance into the voltage converter. The appliance is now ready for use.
5. If the Voltage Converter is overloaded the fuse may blow. The fuse must be replaced with a fuse that is the same type and rating (250V, 10A)
ADAPTER PLUGS
Electrical wall outlets around the world differ in shape, assortment and arrangement of outlet holes. This kit offers five different adapter plugs for use
with the converter and dual voltage appliances.
• ROUND THIN & THICK PINS -- Europe, Middle East, Asia
• FLAT ANGLED BLADES -- Australia, Fiji, New Zealand, China
• FLAT PARALLEL BLADES -- South America, Caribbean, Japan
• 3-SQUARE PINS -- Africa, Hong Kong, Singapore, parts of Great Britain & Ireland
Note: The plugs only enable you to plug your converter or dual voltage appliance into a foreign wall outlet.
WARNING:
• Not for use in North America
• Do not leave the converter plugged into the wall outlet when not in use
• Do not expose to liquid, moisture or humidity
• Do not handle with wet hands
• Do not attempt to disassemble
• Do not use with electronic devices demanding power over
120V, 15A or 240V, 7.5A
SPECIFICATIONS:
Input: 220/240V AC, 50/60Hz
Full load voltage: 110/220 VAC
Input Power: 50/1600W
Rated current: 12A
Fuse rating: 250V 10A
• Unplug immediately should there be any abnormalities such as
smoke or emitted odor
• Do not put metal fragments inside adapter
• Do not use the converter or adapter plug if it is not working properly,
has been damaged or has been dropped in water
• Only use as instructed by this manual
• Keep away from reach of children
• For indoor use only
LEI ELECTRONICS INC. LIMITED WARRANTY
This product is warranted against defects for one (1) year from the date of purchase. Within this period, LEI
Electronics Inc. agrees to remedy such defects by repairing or replacing, at it’s option, any product provided
it is sent PREPAID to the address listed below within the warranty period and includes a copy of the original
sales receipt as proof of purchase.
EXCEPT AS PROVIDED HEREIN, LEI ELECTRONICS INC. MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
This warranty gives you specific legal rights and you may have other rights which will vary from province to
province.
For product support please contact www.leiproducts.com or 1-800-449-3315.
Custom Manufactured in China for/
Fabriqué en Chine spécialement pour
LEI Electronics Inc.,
18 Mollard Court, Unit 4
Barrie, Ontario, Canada L4N 8Y1
www.leiproducts.com
