Legrand 500 Series Small Raceway Multi-Gang Box - Manuel

Multi-Gang Boxes
Installation Instructions
Use #8 (5/16" [7.9mm] head size) flat head fasteners or
equivalent to mount base to surface.
Utliser une attache à tête plate de calibre 8 (tête de 7.9mm, 5/16" po.) ou une fixation équivalente
pour assujettir le tube guide-fils et les raccords à la surface de montage.
Use un sujetador de cabeza plana No. 8 (tamaño de cabeza: 7.9mm, 5/16" de pulgada) o su
equivalente para unir la canalita y los accesorios a la superficie do montaje.
41393 298 © 1998 The Wiremold Company
The Wiremold Company
60 Woodlawn Street
West Hartford, CT 06110
Tel 1-800-621-0049 • Fax 860-232-2062
Wiremold Electrical Systems conform
to and should be installed and properly
grounded in compliance with require-
ments of the current National Electrical
Code, Canadian Electrical Code or
codes administered by local authorities.
All electrical products may represent
possible shock or fire hazard if improp-
erly installed or used. Wiremold electri-
cal products are UL listed. Made for
interior use only and should be installed
in conformance with current local
and/or the National Electrical Code.
1 2
3
5
4
3/8" [9.53mm]
500 700
