UNSHIELDED SHIELDED
TWISTED PAIR TELEPHONE TWISTED
TYPE 24 AWG, 4-PAIR 24 AWG, NO. OF PAIRS COAXIAL TWINAXIAL PAIR FIBER OPTIC
TWO STRAND (DUPLEX)
CAT. 5 CAT. 3 2 3 4 25 RG58/U RG59/U RG62/U RG6/U 100 OHM TYPE 1 TYPE 2 TYPE 3 MULTIMODE, 62.5/125µm
O.D. inches 0.220 0.190 0.140 0.150 0.190 0.410 0.195 0.242 0.242 0.270 0.330 0.390 0.465 0.245 0.190
O.D. [mm] [5.6] [4.8] [3.6] [3.8] [4.8] [10.4] [5.0] [6.1] [6.1] [6.9] [8.4] [9.9] [11.8] [6.2] [4.8]
40% fill 2 3 6 5 3 0 3 2 2 1 1 0 0 2 3
1500 RACEWAY WIRE FILL CAPACITIES FOR DATA/COMMUNICATIONS
1500, 2600, 2100
Two-Piece Metal Raceway
I N S T A L L A T I O N I N S T R U C T I O N S
Installation Instruction No.: 41404R3 – Updated September 2003
Wiremold Electrical Systems conform to and should
be installed and properly grounded in compliance with
requirements of the current National Electrical Code, Canadian
Electrical Code or codes administered by local authorities.
All electrical products may represent possible shock or fire
hazard if improperly installed or used. Wiremold electrical
products are UL Listed to U.S. and Canadian safety
standards, made for interior use only, and should be installed in
conformance with current local and/or the National
Electrical Code.
TYPE AWG,
THHN/THWN 8 10 12 14
O.D. inches 0.216 0.164 0.130 0.111
O.D. [mm] 5.5 4.2 3.3 2.8
40% fill 2 4 6 9
1500 RACEWAY WIRE FILL CAPACITIES FOR POWER
UNSHIELDED SHIELDED
TWISTED PAIR TELEPHONE TWISTED
TYPE 24 AWG, 4-PAIR 24 AWG, NO. OF PAIRS COAXIAL TWINAXIAL PAIR FIBER OPTIC
TWO STRAND (DUPLEX)
CAT. 5 CAT. 3 2 3 4 25 RG58/U RG59/U RG62/U RG6/U 100 OHM TYPE 1 TYPE 2 TYPE 3 MULTIMODE, 62.5/125µm
O.D. inches 0.220 0.190 0.140 0.150 0.190 0.410 0.195 0.242 0.242 0.270 0.330 0.390 0.465 0.245 0.190
O.D. [mm] [5.6] [4.8] [3.6] [3.8] [4.8] [10.4] [5.0] [6.1] [6.1] [6.9] [8.4] [9.9] [11.8] [6.2] [4.8]
40% fill 7 10 18 16 10 2 9 6 6 5 3 2 1 6 10
2600 RACEWAY WIRE FILL CAPACITIES FOR DATA/COMMUNICATIONS
TYPE AWG,
THHN/THWN 8 10 12 14
O.D. inches 0.216 0.164 0.130 0.111
O.D. [mm] 5.5 4.2 3.3 2.8
40% fill 8 13 21 29
2600 RACEWAY WIRE FILL CAPACITIES FOR POWER
UNSHIELDED SHIELDED
TWISTED PAIR TELEPHONE TWISTED
TYPE 24 AWG, 4-PAIR 24 AWG, NO. OF PAIRS COAXIAL TWINAXIAL PAIR FIBER OPTIC
TWO STRAND (DUPLEX)
CAT. 5 CAT. 3 2 3 4 25 RG58/U RG59/U RG62/U RG6/U 100 OHM TYPE 1 TYPE 2 TYPE 3 MULTIMODE, 62.5/125µm
O.D. inches 0.220 0.190 0.140 0.150 0.190 0.410 0.195 0.242 0.242 0.270 0.330 0.390 0.465 0.245 0.190
O.D. [mm] [5.6] [4.8] [3.6] [3.8] [4.8] [10.4] [5.0] [6.1] [6.1] [6.9] [8.4] [9.9] [11.8] [6.2] [4.8]
40% fill 8 11 21 19 11 2 11 7 7 5 3 2 1 7 11
2100 RACEWAY WIRE FILL CAPACITIES FOR DATA/COMMUNICATIONS
TYPE AWG, WITHOUT DEVICES WITH DEVICES (2127G RECEPTACLE)
THHN/THWN 8 10 12 14 8 10 12 14
O.D. inches 0.216 0.164 0.130 0.111 0.216 0.164 0.130 0.111
O.D. [mm] 5.5 4.2 3.3 2.8 5.5 4.2 3.3 2.8
40% fill 2 4 6 9 0 3 5 7
2100 RACEWAY WIRE FILL CAPACITIES FOR POWER
