INSTALLATION & OPERATING:
TRANSPORT & INSTALLATION
During transport of LDV115B/118B/215B/218B PA-Subwoofer please take care of a sufficient protection against
drop over, drop down etc. (e. g. protection with fastening belts during transport). Wearing of working clothes during
carrying of the speakers is recommended (especially work gloves, work boots). To make short distance transport
more easy the subwoofer LDV115B/118B/215B can be equipped with swivel-type castors (accessory, Art.: 37223/
37224). The Subwoofer LDV218B is equipped with 2 castors for transport.
Please do not park the subwoofer standing on the castors on an sloping area, even with activated brake! Please do
not park the subwoofer during a transport in a van etc. standing on the castors!
Uncontrolled run on wheels of the subwoofer can lead to serious accidents!
Please do not install the items directly beside an edge like a stage border.
If a stand is used to place top-units above the subwoofer please make sure to use only undamaged stands (Ø 36
mm) fitting correctly into the support. Please notice also the max. permitted number of stacked subwoofer.
To use the LDV215B together with the Line Array LDVA4 a connection adaptor (accessory) is available to stack up
to 4 LDVA4 on the LDV215B (ground standing operating, see page 6 ).
OPERATING
Please take care for an accurate wiring of the subwoofer. Please use only undamaged cables of an adequate size
(min. 2 x 1.5 mm² for subwoofer connection). Please check the wiring for any kind of trip hazard etc. to prevent
any kind of accidents or damage (Gaffa-Tape).
The terminal of the LDV115B/118B/215B/218B is equipped with a 4-polar Speakon input as well as a 4-polar
Speakon output seat. The connections 1+/- are used by the LDV115B/118B/215B/218B.
All 4 poles of the input seat are connected directly to the 4 poles of the output seat enabling the connection of
further subwoofers even if the connections 2+/- are used.
The connection of further subwoofers decreases the total impedance. Please take care that the total impedance
does not fall below the minimum required impedance of the amplifier.
