ENTRETIEN/NOMENCLATURE DES PIÈCES
5-8 RT80 / RT80M Manuel de l’opérateur
1
Ensemble de torche machine RT80M
N° de
Article référence Description Quantité
087035* RT80M Machine Torch Assembly with 25 ft (7.6 m) Lead
087036* RT80M Machine Torch Assembly with 50 ft (15.2 m) Lead
1 128640 Torch Main Body Replacement Kit 1
2 027889 Retaining Clip 1
3 058519 O-ring 1
4 128639 Cap-off Sensor Replacement Kit 1
5 075571 Cap-off Sensor Screws 2
6 128521 Torch Head Repair Kit 1
7 128643 Torch Mounting Sleeve Replacement Kit 1
8 075618 Torch Mounting Screws 3
9 128710 Torch Positioning Sleeve 1
10 128827 25 ft (7.6 m) Torch Lead Replacement Kit 1
11 128828 50 ft (15.2 m) Torch Lead Replacement Kit 1
12 128826 RT80/RT80M Quick Disconnect Repair Kit 1
128645 Torch Mounting Kit (for reassembly after installation) 1
* L’ensemble supérieur inclut les pièces consommables suivantes (Voir la page 5-4 pour plus de détails sur les
pièces consommables):
120926 Electrode 1
120925 Swirl Ring 1
120928 Retaining Cap 1
120929 Shield 1
120927 Nozzle 1
