Compuprint MDP30FB - Manuel (Page 47)

47
OFFSET TUNING SETUP
Vertical Position Offset (1/10 INCH)
PROGRAM 1 ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 2 ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 3 ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 4 ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
0 +1 +2 +3 +4 +5 +6 +7 +8 +9
Vertical Offset Tuning (1/60 INCH)
X X X X X X X X X X X X X
PROGRAM 1 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 2 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 3 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 4 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( )
-6 -5 -4 -3 -2 -1 0 +1 +2 +3 +4 +5 +6
Horizontal Position Offset (1/10 INCH)
PROGRAM 1 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 2 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 3 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
PROGRAM 4 ( ) ( ) ( ) ( ) ( ) ( ) ( )* ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )
-6 -5 -4 -3 -2 -1 0 +1 +2 +3 +4 +5 +6 +7 +8 +9
Horizontal Offset Tuning (1/60 INCH)
PROGRAM 1 PROGRAM 2 PROGRAM 3 PROGRAM 4
X ( ) ( ) ( ) ( ) -6
X ( ) ( ) ( ) ( ) -5
X ( ) ( ) ( ) ( ) -4
X ( ) ( ) ( ) ( ) -3
X ( ) ( ) ( ) ( ) -2
X ( ) ( ) ( ) ( ) -1
X ( ) * ( ) * ( ) * ( ) * 0
X ( ) ( ) ( ) ( ) +1
X ( ) ( ) ( ) ( ) +2
X ( ) ( ) ( ) ( ) +3
X ( ) ( ) ( ) ( ) +4
X ( ) ( ) ( ) ( ) +5
X ( ) ( ) ( ) ( ) +6
