E0: Safety key not in the position
Put the safety key in the position.
E1: No feedback from controller or speed sensor
5. Check the condition of cables and ensure that all plugs are connected between the motor controller
and display.
6. Check that the speed sensor and magnet are in correct alignment and that there are no obstructions
on the magnet. (The magnet can be found on the front roller near the motor belt).
7. If the running belt moves then displays the E1 error after 10 seconds, replace the speed sensor.
8. If the running belt does not move, replace the controller.
E3: Self-checking failure
4. If the running belt does not move, replace the controller.
5. Ensure that all plugs are connected between the motor controller and display.
6. Check that the speed sensor and magnet are in correct alignment and that there are no obstructions
on the magnet. (The magnet can be found on the front roller near the motor belt).
No Power
1. Check fuses (They are located on the controller under the motor cover )
2. Check power outlet (Plug something else into the power outlet to ensure that the power outlet is working
correctly).
3. Check Power Cable (You may need to take it to an electrician).
To order spare parts
To guarantee an efficient service, make sure you have the following items before you
contact our After Sales Service:
The name or reference of the product.
The manufacturing number shown on the main chassis and on the packing box.
Contact us from Monday to Friday between 10h00 and 12h00 and 14h00 and 17h00 (except for
public holidays).
C.A.R.E. first line
18 / 22 rue Bernard
Z.I. les Vignes 93012 BOBIGNY Cedex
Tel.: 0820 821 167
Fax: 00 33 1 48 43 51 03
Email: [email protected]
