SM2842
1
MAIN FUNCTIONS OF THE WASHING MACHINE
C Optional function buttons
D Spin speed indicator leds
B Delayed start led
H Spin selection button
I
Delayed start button
L Start button
P Programme and temperature knob
S Programme status led
GB
MODEL: WM111XL - WM111XLS - WM111XLB
USING THE WASHING MACHINE
(follow these instructions and the washing machine will run the selected wash cycle)
1. Open the door
2. Load the washing in the drum and close the door.
Warning: Do not overload the machine. It is not advisable to wash items that absorb large quantities
of water such as carpets.
3. Add a low-suds detergent and softener designed for automatic washing machines in the respective
compartments of the detergent drawer (see chapter “ USE OF DETERGENTS”).
4. Close the detergent drawer. Do not open the drawer while the machine is working as this may
cause water to spill out.
5. Rotate the programmer knob (P) to select the required programme and temperature according to
the type of fabric to wash (see: “ PROGRAMME TABLES”)
N.B.: When selecting a program, the led of maximum spin speed allowed by the
program selected will automatically light up. One of the leds (S) will light up to
indicate the starting wash cycle.
6. Select the required spin speed by pressing button (H) (see “VARIABLE SPIN”).
7. Select the (C) buttons with the functions required (see “OPTIONAL FUNCTIONS”).
8. Press button (I) if required (see “DELAYED START”).
9. Press button (L) to start the wash cycle (see “START BUTTON”).
10. At the end of the wash cycle, turn the program selector knob (P) on “STOP”.
11. OWith dry hands, unplug the washing machine from the mains supply.
12. Open the door and remove the washing.
13. Close the water feed valve.
WASH CYCLE:
“EASY LOGIC” TECHNOLOGY
The electronic washing machine is fitted with an “EASY LOGIC” system that automatically
recognises the quantity of washing loaded. The machine can thus regulate the amount of water
to use for the wash and proportion the wash time accordingly, thus saving water, time and
energy. In the case where the amount of washing is less than the maximum recommended
load (see technical characteristics table), the quantity of water used for the wash will be re-
duced by 2 litres for each kg less of washing. In the case of a half-load or less, the machine
will automatically carry out one rinse less than programmed.
N.B. The “EASY LOGIC” function is only active for cotton programmes.
