5. CARE & CLEANING
Note: Do NOT use abrasive materials or chemical cleaners.
1. Clean cabinet surfaces with a soft cloth and warm soapy water. Dry it with a cloth
2. Brush off dust from the radiator (12) located at back of dispenser to improve
efficiency.
CLEANING COLD TANK
Recommended to be done every 2 to 3 months depending on the water type
1. Best to do prior to loading a fresh bottle
2. Turn off both switches on back
3. Unplug power cord
4. Remove water bottle
5. Place at least a 10 Litre bucket under the drain of the dispenser (found on the back
side)
6. Remove drain cap and silicon plug. Cold water will flow into the bucket. This will
be followed several seconds later by hot water at temperatures that can cause severe
burns. Avoid direct contact with hot water.
7. Place drain cap and silicon plug in a safe location so they are not lost.
8. Keep children away while draining the dispenser
9. Remove remaining water from the reservoirs by dispensing from both taps
10. Replace silicon plug and drain cap
11. Remove water guard (1) assembly by turning it counter clockwise.
12. Clean water guard assembly with a soft cloth using a cleaning mixture with 2%
cooking citric acid and 5 litres of clean water and then rinse the water guard and place
it on a clean cloth.
13. Pour remaining cleaning mixture into the tank
14. Dispense all cleaning mixture through the both taps
15. Wipe inside of reservoir and area around both taps with a soft cloth
16. Rinse system twice by dispensing 5 litres of tap water through both taps
17. Make sure all water has been dispensed.
18. Replace water guard assembly
19. Repeat INSTALLATION procedure as mentioned previously
