FRIGIDAIRE CFES365EC - Manuel

1
Bake time
Temps de
cuisson
Controls
Self-Cleaning Oven
Four Autonettoyant
Oven
Four
Preheat
Préchauffage
Door Locked
Porte Verrouillée
Clean
Nettoyer
Bake
Cuire
Broil
Griller
Start time
Heure de
départ
Timer
On/Off
Minuterie
Clock
Horloge
Clear/Off
Annuler
ELECTRONIC OVEN CONTROL GUIDE
NOTE: The basic timer is externally arranged in different configuration in various appliance models. This does not
change the way it operates.
NOTE: Some models have a touch pad control. To activate it, you just have to touch the pad with a finger. Take care to
have a good contact between the finger and the touch pad. Long nails can make the activation difficult. It is a good idea
to clean the control panel after each use or as soon as possible after a spill, boil over or spatter because some ionic
or salty ingredients as ketchup, tomatoes sauce, etc. can operate the control. Before cleaning the control panel it is
recommended to turn on the control lockout feature.
318200183 (0903) Rev. B Printed in United States
Control Pad Functions
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar
with the various functions of the oven as described below.
Note: The time of day must first be set in order to operate the oven.
BROIL PAD—
Used to select
the variable broil
function.
UP and DOWN ARROW PADS— Used along
with the function pads to select oven temperature,
cook time, start time (when programming an
automatic start time), time of day, clean time
and minute timer. BAKE
PAD—Used to
select the bake
function.
START TIME PAD— Used
to set the desired start time
for baking & Self-Clean. May
be used with COOK TIME to
program a delayed bake or
clean cycle.
BAKE TIME
PAD— Used to
enter the length
of the baking
time.
SELECT SELF-
CLEAN PAD—
Used to select the
Self-Cleaning cycle.
A 2 or 3 hour Self-
Clean time may be
selected.
OVEN, PREHEAT & DOOR LOCKED LIGHTS* — The "OVEN" light will glow each
time the oven turns on to maintain the set oven temperature. The "PREHEAT" light
will glow when the oven is first set to operate, or if the desired temperature is reset
higher than the actual oven temperature. The "DOOR LOCKED" light will flash when
the oven door locks and unlocks or when using the Self-Clean cycle or the oven door
lockout is activated. The indicator light will glow constantly after the door locks.
FEATURE
INDICATOR
LIGHTS— These light
to show which feature
is in use. CLOCK
SET PAD—
Used to set
the time of
day.
CLEAR OFF PAD—
Used to clear any
function previously
entered except the
time of day and minute
timer. Press CLEAR
OFF to stop cooking.
Also the CLEAR OFF
pad is used to activate
controls and oven door
lockout setting.
TIMER ON/OFF
PAD— Used to
set or cancel
the minute timer.
The minute timer
does not start
or stop cooking.
Also, TIMER
ON/OFF pad is
used to set the
Continuous Bake
feature.
*Note: The OVEN indicator light on the electronic display will turn ON and OFF when using the Bake feature and during
preheat. This is normal and indicates that the oven is cycling to maintain the selected baking temperature. When the
preheat indicator light turns OFF, your oven is ready.
For a silent control panel
When choosing a function, a beep will be heard each time a pad is pressed. If desired, the control can be programmed for
silent operation. Press and hold
Start time
Heure de
départ . After 7 seconds, the control will beep once. This will block the controls from sounding
when a pad is pressed. To return the sound, press and hold
Start time
Heure de
départ again for 7 seconds until the control beeps once.
