Curtis DCD5159 Quick Start Manuel d'utilisation

Quick start guide

Advertising
background image

2

1

3

4

5

14

15

16

18

17

13

11

20

19

12

6

7

8

10

9

Quick Start Guide

DCD5159

1. POWER button

2. SHUTTER button

3. Flash

4. Viewfinder

5. Lens

6. Function light

7. Charging light

8. REC mode

9. Mode switch

10. PLAY mode

11. UP button

12. RIGHT button

13. OK button

14. DOWN button

15. Battery cover

16. LEFT button

17. MENU/DISP button

18. LCD screen

19. TV jack

20. USB port

Quick Start

• Unpack the carton and take out your camera.

• Slide to open the battery compartment cover and load 2 AAA batteries (recommend

using the recharged batteries) following the marked.

• Close the battery compartment cover.

Take Pictures

• Press the POWER button to turn on your camera.

• Turn the mode switch to REC position.

• Target your subject in the LCD or in the viewfinder. If the LCD is off, please press

the DOWN button to turn on.

• Press the RIGHT button to select the desired snap mode.

• Press the LEFT button to select the desired flash mode.

• Adjust the distance, and center your subject in the LCD, then press the SHUTTER

button to capture a picture.

View Pictures

• Press the POWER button to turn on your camera.

• Turn the mode switch to PLAY position.

• Press the LEFT/RIGHT buttons to iterate through your pictures.

• Press the UP button to enter thumbnail mode (9 pictures will be displayed on

the LCD).

• In thumbnail mode, you can press the LEFT/RIGHT buttons to select the desired

picture, and press UP button to display it singly on the LCD.

Download Pictures to PC

• Turn the mode switch to PLAY position.

• Plug in the USB cable to the PC USB port and your camera USB port.

• Your camera will enter the “Mass Storage” mode. And the removable disk will

appear in your PC.

• Now you can download the pictures in your camera to your PC (if your PC’s OS

is windows 98, you must install the camera driver in your PC firstly).
