16

COOKTOP CONTROLS

To avoid damage to the cooktop controls, do not use steel wool,
abrasive cleansers or oven cleaner.

To avoid damage, do not soak knobs.

When removing or replacing knobs, make sure knobs are in the
Off position.

Do not remove seals under knobs, if present.

Cleaning Method:

Warm, soapy water:

Pull knobs straight away from control panel to remove.

CONTROL PANEL

To avoid damage to the control panel, do not use abrasive
cleaners, steel-wool pads, gritty washcloths or abrasive paper
towels.

To avoid turning the controls on while cleaning, you may activate
the Control Lock feature (on some models). See “Control Lock”
section.

Cleaning Method:

Glass cleaner and soft cloth or sponge:

Apply glass cleaner to soft cloth or sponge, not directly on
panel.

All-Purpose Appliance Cleaner Part Number 31682 (not
included):

See “Assistance or Service” section to order.

OVEN DOOR EXTERIOR

Cleaning Method:

Glass cleaner and paper towels or nonabrasive plastic
scrubbing pad: Apply glass cleaner to soft cloth or sponge,
not directly on panel.

All-Purpose Appliance Cleaner Part Number 31682 (not
included):

See “Assistance or Service” section to order.

OVEN CAVITY

Do not use oven cleaners.

Food spills should be cleaned when oven cools. At high
temperatures, foods react with porcelain and staining, etching,
pitting or faint white spots can result.

Cleaning Method:

Self-Cleaning cycle: See “Self-Cleaning Cycle” first.

OVEN RACKS

Cleaning Method:

Self-Cleaning cycle:

See “Self-Cleaning Cycle” first. Remove racks, or they will
discolor and become harder to slide. If this happens, a light
coating of vegetable oil applied to the rack guides will help
them slide.

Steel-wool pad

STORAGE DRAWER (on some models)

Make sure drawer is cool and empty before cleaning.

For more information, see “Storage Drawer” section.

Cleaning Method:

Mild detergent

Drawer Liner (on some models)

Remove all stored items from drawer and lift out drawer liner.

Clean with mild detergent

All-Purpose Appliance Cleaner Part Number 31682 (not
included):

See “Assistance or Service” section to order.

Oven Light

The oven light is a standard 40-watt appliance bulb. Before
replacing, make sure the oven and cooktop are cool and the
control knobs are in the off position.

To Replace:

1. Unplug range or disconnect power.

2. Turn the glass bulb cover in the back of the oven

counterclockwise to remove.

3. Turn bulb counterclockwise to remove from socket.

4. Replace bulb, then bulb cover by turning clockwise.

5. Plug in range or reconnect power.

Storage Drawer

(on some models)

The storage drawer can be removed. Before removing, make sure
drawer is cool and empty.

To Remove:

1. Pull storage drawer out to the first stop position.

2. Lift up the front of the drawer and pull the drawer out to the

second stop position.

3. Grasp sides and lift drawer top up and out.

To Replace:

1. Fit the ends of the drawer glides into the rails in the range.

2. Lift up the front of the drawer and gently push in to the first

stop position.

3. Lift drawer up again and push until drawer is closed.
